post

How Do You Appreciate Fedora?

This week is the first annual Fedora Appreciation Week. As an extension of the How Do You Fedora? series, this article presents how past interviewees appreciate Fedora. The Fedora Project defines four common values that it encourages all contributors and community members to uphold. Those values are known as the Four Foundations. One such value, Friends, represents the vibrant community of contributors and users from across the world, all working towards the same goal: advancing free software.

Like any community, the Fedora community evolves over time. Each contributor’s story is a little different. That diversity is what makes the Fedora community so strong. Kernel contributor Justin Forbes puts it succinctly:

Fedora is the community. So much of what Fedora is now came as a direct result of community effort.

Fedora is successful today because of the many contributors, both past and present, who have put their time and effort into the project. Here are some of their stories, and how they appreciate others in the community.

You can click on any of the story headers to see our original interviews with these notable people.

Maria Leandro’s story

Fedora has been a huge part of my personal and professional life, so choosing a top moment would leave several fantastic stories behind. I do remember that first time I went to a Flock and meet personally people that I had been interacting, learning from and teaching for almost 5 years. For people like us who spend most of our time behind a screen, having that personal meeting can be life changing. That particular moment is not about the goals or the tasks that need to be done, that moment is the prize to people who work for a common well, for those who change people’s life without asking anything in return, it’s the moment when you put a face to those commits and bugs, to those wallpapers and docs; it’s the moment when we stop being a random robot name to be real… that moment when we hug each other and greet, that has to be the best moment in all Open Source History.

Maria has two favorite wallpapers from Fedora releases:

Fedora Core 7 Wallpaper

Fedora 26 Wallpaper

She sends a special thank you to appreciate Máirín Duffy, who leads the Fedora design team:

Definitely my hero, mo (mizmo). She pushed me to be the designer I am today, always had a chat to solve any doubt I had, and is the most friendly person you can meet.

Maria’s most memorable release was early on:

Probably Fedora 6, since it was the first time I did any artwork at all for the community.

Michael Larabel’s story

Without a doubt the best Fedora memory with friends would have to be celebrating the Fedora “Beefy Miracle” release back in 2012 at LinuxTag in Berlin where the Fedora booth played it so well and was serving up free hot dogs to go with the delicious beverages of the region. Lots of good catching up with open-source contributors, discussing new ideas, and more during the wonderful community-driven open-source events particularly in Europe.

Michael’s favorite Fedora desktop wallpaper will be familiar to current readers of the Magazine. It’s the brand new wallpaper for Fedora 29:

Fedora 29 Wallpaper

Michael also sent a special thank you to a very special contributor who died in 2013:

The late Seth Vidal earns much respect for his contributions to Fedora, Yum, and Red Hat communities. His technical achievements were great and he was a kind and interesting person at conferences, etc.

His favorite release was Fedora Core 3:

Fedora Core 3 certainly holds a special place in my heart as it was the first Fedora release I really became intrigued by as it was in much better shape than FC1/FC2. Since there it improved while overall from say Fedora 26 and newer, each release has felt particularly polished and keeps getting better — including Fedora 29 and my experience with it thus far on many test boxes.

Julita Inca’s story

Julita shared with us this photo from a recent Women in Fedora event, celebrating the positive impact and contributions of women in the Fedora community:


Fedora WOmen Event with Julita Inca

Her favorite Fedora wallpaper is from the Fedora 17 release:

Fedora 17 Wallpaper

Julita also took time to appreciate one of Fedora’s amazing Czech community contributors and organizers:

The person I admired since the beginning was Jiri Eischmann! He is a polite person and very active in his community. He continues to inspire me to this day! I hope to soon attend a celebration of Fedora in Europe where I am living now.

Author’s Postscript

As a fellow Fedoran I would like to thank each of the people who responded to my questions and all of the previous interviewees. Writing the How Do You Fedora? series has been immensely rewarding for me. I have learned about lots of new applications and uses of Fedora. The greatest impact of the series is that it reignites my faith in the goodness of the people who make up the Fedora community with each installment.

post

Celebrate Fifteen Years of Fedora

On November 6, 2003, Red Hat announced Fedora Core 1, the first software release of the Fedora Project. This announcement marked the beginning of a collaborative project between Red Hat and its user community.

A history lesson

The Fedora Project traces its roots to a community-led project called fedora.us.

Fedora is a community project to ease publishing and delivery of 3rd party software on the Red Hat platform.

At the time, Red Hat Linux provided a core set of packages suitable for most users. The Fedora project set themselves up as a community of dedicated Red Hat Linux users with a goal of finding and packaging more software that was not shipped in the core Red Hat Linux product offering.

A few months after launching Fedora.us, an even bigger announcement hit the fedora.us homepage. Red Hat Linux was merging with Fedora Linux, resulting in the Fedora Project. 🎂

The Fedora Project was now a single, community-based team of passionate Linux developers, many of whom were still Red Hat employees. However, the projects were still somewhat separate. Red Hat Linux became Fedora Core; an openly developed project but was restricted to Red Hat employees. Fedora.us (or Fedora Linux) became Fedora Extras, where community members could continue to contribute packages and enhancements on top of Fedora Core.

This structure continued to exist for six releases of Fedora Core. With the release of Fedora 7, the distinction between Fedora Core and Fedora Extras was dropped, and Fedora was one big, happy family!

What’s new in Fedora Core 1

The Linux software ecosystem 15 years ago looked very different that today. Fedora Core 1 introduced a few new packages that might sound familiar to the astute reader:

  • bitstream-vera-fonts
  • dbus
  • epiphany
  • nano
  • rhythmbox
  • yum

Innovation and early adoption has been a part of Fedora since the beginning. Even in 2003, the Fedora Project was pushing forward with new projects. The following are excerpts from the Fedora Core 1 Release Notes.

  • “CUPS is now the only print spooler provided. During upgrades, if LPRng is installed, it will be replaced by CUPS.”
  • “Fedora Core 1 includes the Native POSIX Thread Library (NPTL), a new implementation of POSIX threads for Linux. This library provides performance improvements and increased scalability.”
  • “Fedora Core 1 now uses a graphical interface while booting.”

Not only that, Fedora was in the process of migrating its font system to the new fontconfig/Xft, and switching to UTF-8 across the distribution!

Default desktop

Even in 2003, GNOME was the default desktop for Fedora.

Fedora Core 1 shipped GNOME 2.4, adopting the classic Red Hat Linux panel layout over the upstream project’s two-panel layout.

The Mozilla Suite was the go-to web browser at the time. Mozilla had not yet started the Firefox standalone browser project, so this suite included an email client and usenet news reader. While Mozilla included an email client, Fedora defaulted to Ximian Evolution as its email/groupware program.

Also included:

  • OpenOffice.org (formerly StarOffice, and not yet LibreOffice)
  • gAIM (Pidgin would rise in popularity as alternatives to AIM came about, such as Yahoo! Messenger and MSN Messenger)
  • X-Chat

Hardware requirements

Fedora Core 1 has some pretty modest hardware requirements, even for 2003.

CPU

At a minimum, it requires a Pentium-class CPU. The release notes include an important note about compiler optimizations.

NOTE: Fedora Core 1 is optimized for Pentium PRO (and later) CPUs, but also supports Pentium-class CPUs. This approach has been taken because Pentium-class optimizations actually result in reduced performance for non-Pentium-class processors.

For a graphical installation (an X11-powered desktop), a 400 MHz Pentium II is recommended. And for text-mode only, a 200 MHz Pentium-class or better!

Hard Disk Space

The release notes list a few different space requirements, depending on the intended use:

  • Custom Installation (Minimal): 520MB
  • Server: 870MB
  • Personal Desktop: 1.9GB
  • Workstation: 2.4GB
  • Custom Installation (Everything): 5.3GB

In today’s world of terabytes of cloud storage, the modest difference in megabytes between a “Server” and “Personal Desktop” seems downright quaint in comparison.

Memory

There is evidence of Moore’s Law in the memory requirements for Fedora Core 1 too. At a minimum, for “text-mode”, it requires 64 MB! And for graphical installations, that increases to 192 MB at a minimum, but recommends at least 256 MB.

Try it out!

Fedora is proud of its heritage. There is no better way to understand history than to experience it. Fortunately, modern virtualization software ships with Fedora Workstation by default! So why not try out Fedora Core 1 yourself? We’ve put together a virtual disk image of Fedora Core 1 (927 MB download) that can be imported directly into GNOME Boxes. It even points to the “current” update repositories so you can try out the “new” yum package manager yourself.

post

Create a containerized machine learning model

After data scientists have created a machine learning model, it has to be deployed into production. To run it on different infrastructures, using containers and exposing the model via a REST API is a common way to deploy a machine learning model. This article demonstrates how to roll out a TensorFlow machine learning model, with a REST API delivered by Connexion in a container with Podman.

Preparation

First, install Podman with the following command:

sudo dnf -y install podman

Next, create a new folder for the container and switch to that directory.

mkdir deployment_container && cd deployment_container

REST API for the TensorFlow model

The next step is to create the REST-API for the machine learning model. This github repository contains a pretrained model, and well as the setup already configured for getting the REST API working.

Clone this in the deployment_container directory with the command:

git clone https://github.com/svenboesiger/titanic_tf_ml_model.git

prediction.py & ml_model/

The prediction.py file allows for a Tensorflow prediction, while the weights for the 20x20x20 neural network are located in folder ml_model/.

swagger.yaml

The file swagger.yaml defines the API for the Connexion library using the Swagger specification. This file contains all of the information necessary to configure your server to provide input parameter validation, output response data validation, URL endpoint definition.

As a bonus Connexion will provide you also with a simple but useful single page web application that demonstrates using the API with JavaScript and updating the DOM with it.

swagger: "2.0" info: description: This is the swagger file that goes with our server code version: "1.0.0" title: Tensorflow Podman Article consumes: - "application/json" produces: - "application/json" basePath: "/" paths: /survival_probability: post: operationId: "prediction.post" tags: - "Prediction" summary: "The prediction data structure provided by the server application" description: "Retrieve the chance of surviving the titanic disaster" parameters: - in: body name: passenger required: true schema: $ref: '#/definitions/PredictionPost' responses: '201': description: 'Survival probability of an individual Titanic passenger' definitions: PredictionPost: type: object

server.py & requirements.txt

server.py  defines an entry point to start the Connexion server.

import connexion app = connexion.App(__name__, specification_dir='./') app.add_api('swagger.yaml') if __name__ == '__main__': app.run(debug=True)

requirements.txt defines the python requirements we need to run the program.

connexion tensorflow pandas

Containerize!

For Podman to be able to build an image, create a new file called “Dockerfile” in the deployment_container directory created in the preparation step above:

FROM fedora:28 # File Author / Maintainer MAINTAINER Sven Boesiger <donotspam@ujelang.com> # Update the sources RUN dnf -y update --refresh # Install additional dependencies RUN dnf -y install libstdc++ RUN dnf -y autoremove # Copy the application folder inside the container ADD /titanic_tf_ml_model /titanic_tf_ml_model # Get pip to download and install requirements: RUN pip3 install -r /titanic_tf_ml_model/requirements.txt # Expose ports EXPOSE 5000 # Set the default directory where CMD will execute WORKDIR /titanic_tf_ml_model # Set the default command to execute # when creating a new container CMD python3 server.py

Next, build the container image with the command:

podman build -t ml_deployment .

Run the container

With the Container image built and ready to go, you can run it locally with the command:

podman run -p 5000:5000 ml_deployment

Navigate to http://0.0.0.0:5000/ui in your web browser to access the Swagger/Connexion UI and to test-drive the model:

Of course you can now also access the model with your application via the REST-API.

post

Upgrading Fedora 28 to Fedora 29

Fedora 29 was just officially released. You’ll likely want to upgrade your system to the latest version of Fedora. Fedora Workstation has a graphical upgrade method. Alternatively, Fedora offers a command-line method for upgrading Fedora 28 to Fedora 29.

Upgrading Fedora 28 Workstation to Fedora 29

Soon after release time, a notification appears to tell you an upgrade is available. You can click the notification to launch the GNOME Software app. Or you can choose Software from GNOME Shell.

Choose the Updates tab in GNOME Software and you should see a window like this:



If you don’t see anything on this screen, try using the reload tool at the top left. It may take some time after release for all systems to be able to see an upgrade available.

Choose Download to fetch the upgrade packages. You can continue working until you reach a stopping point, and the download is complete. Then use GNOME Software to restart your system and apply the upgrade. Upgrading takes time, so you may want to grab a coffee and come back to the system later.

Using the command line

If you’ve upgraded from past Fedora releases, you are likely familiar with the dnf upgrade plugin. This method is the recommended and supported way to upgrade from Fedora 28 to Fedora 29. Using this plugin will make your upgrade to Fedora 29 simple and easy.

1. Update software and back up your system

Before you do anything, you will want to make sure you have the latest software for Fedora 28 before beginning the upgrade process. To update your software, use GNOME Software or enter the following command in a terminal.

sudo dnf upgrade --refresh

Additionally, make sure you back up your system before proceeding. For help with taking a backup, see the backup series on the Fedora Magazine.

2. Install the DNF plugin

Next, open a terminal and type the following command to install the plugin:

sudo dnf install dnf-plugin-system-upgrade

3. Start the update with DNF

Now that your system is up-to-date, backed up, and you have the DNF plugin installed, you can begin the upgrade by using the following command in a terminal:

sudo dnf system-upgrade download --releasever=29

This command will begin downloading all of the upgrades for your machine locally to prepare for the upgrade. If you have issues when upgrading because of packages without updates, broken dependencies, or retired packages, add the ‐‐allowerasing flag when typing the above command. This will allow DNF to remove packages that may be blocking your system upgrade.

4. Reboot and upgrade

Once the previous command finishes downloading all of the upgrades, your system will be ready for rebooting. To boot your system into the upgrade process, type the following command in a terminal:

sudo dnf system-upgrade reboot

Your system will restart after this. Many releases ago, the fedup tool would create a new option on the kernel selection / boot screen. With the dnf-plugin-system-upgrade package, your system reboots into the current kernel installed for Fedora 28; this is normal. Shortly after the kernel selection screen, your system begins the upgrade process.

Now might be a good time for a coffee break! Once it finishes, your system will restart and you’ll be able to log in to your newly upgraded Fedora 29 system.

Upgrading Fedora: Upgrade complete!

Resolving upgrade problems

On occasion, there may be unexpected issues when you upgrade your system. If you experience any issues, please visit the DNF system upgrade wiki page for more information on troubleshooting in the event of a problem.

If you are having issues upgrading and have third-party repositories installed on your system, you may need to disable these repositories while you are upgrading. For support with repositories not provided by Fedora, please contact the providers of the repositories.

post

Design faster web pages, part 3: Font and CSS tweaks

Welcome back to this series of articles on designing faster web pages. Part 1 and part 2 of this series covered how to lose browser fat through optimizing and replacing images. This part looks at how to lose additional fat in CSS (Cascading Style Sheets) and fonts.

Tweaking CSS

First things first: let’s look at where the problem originates. CSS was once a huge step forward. You can use it to style several pages from a central style sheet. Nowadays, many web developers use frameworks like Bootstrap.

While these frameworks are certainly helpful, many people simply copy and paste the whole framework. Bootstrap is huge; the “minimal” version of 4.0 is currently 144.9 KB. Perhaps in the era of terabytes of data, this isn’t much. But as they say, even small cattle makes a mess.

Look back at the getfedora.org example. Recall in part 1, the first analysis showed the CSS files used nearly ten times more space than the HTML itself. Here’s a display of the stylesheets used:

That’s nine different stylesheets. Many styles in them that are also unused on the page.

Remove, merge, and compress/minify

The font-awesome CSS inhabits the extreme end of included, unused styles. There are only three glyphs of the font used on the page. To make that up in KB, the font-awesome CSS used at getfedora.org is originally 25.2 KB. After cleaning out all unused styles, it’s only 1.3 KB. This is only about 4% of its original size! For Bootstrap CSS, the difference is 118.3 KB original, and 13.2 KB after removing unused styles.

The next question is, must there be a bootstrap.css and a font-awesome.css? Or can they be combined? Yes, they can. That doesn’t save much file space, but the browser now requests fewer files to succesfully render the page.

Finally, after merging the CSS files, try to remove unused styles and minify them. In this way, you save 10.1 KB for a final size of 4.3 KB.

Unfortunately, there’s no packaged “minifier” tool in Fedoras repositories yet. However, there are hundreds of online services to do that for you. Or you can use CSS-HTML-JS Minify, which is Python, and therefore easy to isntall. There’s not an available tool to purify CSS, but there are web services like UnCSS.

Font improvement

CSS3 came with something a lot of web developer like. They could define fonts the browser downloads in the background to render the page. Since then, a lot of web designers are very happy, especially after they discovered the usage of icon fonts for web design. Font sets like Font Awesome are quiet popular today and widely used. Here’s the size of that content:

current free version 912 glyphs/icons, smallest set ttf 30.9KB, woff 14.7KB, woff2 12.2KB, svg 107.2KB, eot 31.2

So the question is, do you need all the glyphs? In all probability, no. You can get rid of them with FontForge, but that’s a lot of work. You could also use Fontello. Use the public instance, or set up your own, as it’s free software and available on Github.

The downside of such customized font sets is you must host the font by yourself. You can’t use other online font services to provide updates. But this may not really be a downside, compared to faster performance.

Conclusion

Now you’ve done everything you can to the content itself, to minimize what the browser loads and interprets. From now on, only tricks with the administration of the server can help.

One easy to do, but which many people do wrong, is decide on some intelligent caching. For instance, a CSS or picture file can be cached for a week. Whatever you do, if you use a proxy service like Cloudflare or build your own proxy, minimze the pages first. Users like fast loading pages. They’ll (silently) thank you for it, and the server will have a smaller load, too.

post

4 cool new projects to try in COPR for October 2018

COPR is a collection of personal repositories for software that isn’t carried in the standard Fedora repositories. Some software doesn’t conform to standards that allow easy packaging. Or it may not meet other Fedora standards, despite being free and open source. COPR can offer these projects outside the standard set of Fedora Fedora packages. Software in COPR isn’t supported by Fedora infrastructure or signed by the project. However, it can be a neat way to try new or experimental software.

Here’s a set of new and interesting projects in COPR.

GitKraken

GitKraken is a useful git client for people who prefer a graphical interface over command-line, providing all the features you expect. Additionally, GitKraken can create repositories and files, and has a built-in editor. A useful feature of GitKraken is the ability to stage lines or hunks of files, and to switch between branches fast. However, in some cases, you may experience performance issues with larger projects.

Installation instructions

The repo currently provides GitKraken for Fedora 27, 28, 29 and Rawhide, and for OpenSUSE Tumbleweed. To install GitKraken, use these commands:

sudo dnf copr enable elken/gitkraken sudo dnf install gitkraken

Music On Console

Music On Console player, or mocp, is a simple console audio player. It has an interface similar to the Midnight Commander and is easy use. You simply navigate to a directory with music files and select a file or directory to play. In addition, mocp provides a set of commands, allowing it to be controlled directly from command line.

Installation instructions

The repo currently provides Music On Console player for Fedora 28 and 29. To install mocp, use these commands:

sudo dnf copr enable Krzystof/Moc sudo dnf install moc

cnping

Cnping is a small graphical ping tool for IPv4, useful for visualization of changes in round-trip time. It offers an option to control the time period between each packet as well as the size of data sent. In addition to the graph shown, cnping provides basic statistics on round-trip times and packet loss.

Installation instructions

The repo currently provides cnping for Fedora 27, 28, 29 and Rawhide. To install cnping, use these commands:

sudo dnf copr enable dreua/cnping sudo dnf install cnping

Pdfsandwich

Pdfsandwich is a tool for adding text to PDF files which contain text in an image form — such as scanned books. It uses optical character recognition (OCR) to create an additional layer with the recognized text behind the original page. This can be useful for copying and working with the text.

Installation instructions

The repo currently provides pdfsandwich for Fedora 27, 28, 29 and Rawhide, and for EPEL 7. To install pdfsandwich, use these commands:

sudo dnf copr enable merlinm/pdfsandwich sudo dnf install pdfsandwich
post

Edit your videos with Pitivi on Fedora

Looking to produce a video of your adventures this weekend? There are many different options for editing videos out there. However, if you are looking for a video editor that is simple to pick up, and also available in the official Fedora Repositories, give Pitivi a go.

Pitivi is an open source, non-linear video editor that uses the GStreamer framework. Out of the box on Fedora, Pitivi supports OGG Video, WebM, and a range of other formats. Additionally, more support for for video formats is available via gstreamer plugins. Pitivi is also tightly integrated with the GNOME Desktop, so the UI will feel at home among the other newer applications on Fedora Workstation.

Installing Pitivi on Fedora

Pitivi is available in the Fedora Repositories. On Fedora Workstation, simply search and install Pitivi from the Software application.

Alternatively, install Pitivi using the following command in the Terminal:

sudo dnf install pitivi

Basic Editing

Pitivi has a wide range of tools built-in to allow quick and effective editing of your clips. Simply import videos, audio, and images into the Pitivi media library, then drag them onto the timeline. Additionally, pitivi allows you to easily split, trim, and group parts of clips together, in addition to simple fade transitions on the timeline.

Transitions and Effects

In addition to a basic fade between two clips, Pitivi also features a range of different transitions and wipes. Additionally, there are over a hundred effects that can be applied to either videos or audio to change how the media elements are played or displayed in your final presentation


Pitivi also features a range of other great features, so be sure to check out the tour on their website for a full description of the features of the awesome Pitivi.

post

Design faster web pages, part 2: Image replacement

Welcome back to this series on building faster web pages. The last article talked about what you can achieve just through image compression. The example started with 1.2MB of browser fat, and reduced down to a weight of 488.9KB. That’s still not fast enough! This article continues the browser diet to lose more fat. You might think that partway through this process things are a bit crazy, but once finished, you’ll understand why.

Preparation

Once again this article starts with an analysis of the web pages. Use the built-in screenshot function of Firefox to make a screenshot of the entire page. You’ll also want to install Inkscape using sudo:

$ sudo dnf install inkscape

If you want to know how to use Inkscape, there are already several articles in Fedora Magazine. This article will only explain some basic tasks for optimizing an SVG for web use.

Analysis

Once again, this example uses the getfedora.org web page.

Getfedora page with graphics marked

Getfedora page with graphics marked

This analysis is better done graphically, which is why it starts with a screenshot. The screenshot above marks all graphical elements of the page. In two cases or better in four cases, the Fedora websites team already used measures to replace images. The icons for social media are glyphs from a font and the language selector is an SVG.

There are several options for replacing:

HTML5 Canvas

Briefly, HTML5 Canvas is an HTML element that allows you to draw with the help of scripts, mostly JavaScript, although it’s not widely used yet. As you draw with the help of scripts, the element can also be animated. Some examples of what you can achieve with HTML Canvas include this triangle pattern, animated wave, and text animation. In this case, though, it seems not to be the right choice.

CSS3

With Cascading Style Sheets you can draw shapes and even animate them. CSS is often used for drawing elements like buttons. However, more complicated graphics via CSS are usually only seen in technical demonstration pages. This is because graphics are still better done visually as with coding.

Fonts

The usage of fonts for styling web pages is another way, and Fontawesome is quiet popular. For instance, you could replace the Flavor and the Spin icons with a font in this example. There is a negative side to using this method, which will be covered in the next part of this series, but it can be done easily.

SVG

This graphics format has existed for a long time and was always supposed to be used in the browser. For a long time not all browsers supported it, but that’s history. So the best way to replace pictures in this example is with SVG.

Optimizing SVG for the web

To optimize an SVG for internet use requires several steps.

SVG is an XML dialect. Components like circle, rectangle, or text paths are described with nodes. Each node is an XML element. To keep the code clean, an SVG should use as few nodes as possible.

The SVG example is a circular icon with a coffee mug on it. You have 3 options to describe it with SVG.

Circle element with the mug on top

<circle style="opacity:1;fill:#717d82;fill-opacity:1;stroke:none;stroke-width:9.51950836;stroke-linecap:round;stroke-linejoin:round;stroke-miterlimit:4;stroke-dasharray:none;stroke-dashoffset:0;stroke-opacity:1;paint-order:markers fill stroke" id="path36" cx="68.414307" cy="130.71523" r="3.7620001" />

Circular path with the mug on top

<path style="opacity:1;fill:#717d82;fill-opacity:1;stroke:none;stroke-width:1.60968435;stroke-linecap:round;stroke-linejoin:round;stroke-miterlimit:4;stroke-dasharray:none;stroke-dashoffset:0;stroke-opacity:1;paint-order:markers fill stroke" d="m 68.414044,126.95318 a 3.7618673,3.7618673 0 0 0 -3.76153,3.76204 3.7618673,3.7618673 0 0 0 3.76153,3.76205 3.7618673,3.7618673 0 0 0 3.76206,-3.76205 3.7618673,3.7618673 0 0 0 -3.76206,-3.76204 z" id="path20" />

single path

<path style="opacity:1;fill:#717d82;fill-opacity:1;stroke:none;stroke-width:1.60968435;stroke-linecap:round;stroke-linejoin:round;stroke-miterlimit:4;stroke-dasharray:none;stroke-dashoffset:0;stroke-opacity:1;paint-order:markers fill stroke" d="m 68.414044,126.95318 a 3.7618673,3.7618673 0 0 0 -3.76153,3.76204 3.7618673,3.7618673 0 0 0 3.76153,3.76205 3.7618673,3.7618673 0 0 0 3.76206,-3.76205 3.7618673,3.7618673 0 0 0 -3.76206,-3.76204 z m -1.21542,0.92656 h 2.40554 c 0.0913,0.21025 0.18256,0.42071 0.27387,0.63097 h 0.47284 v 0.60099 h -0.17984 l -0.1664,1.05989 h 0.24961 l -0.34779,1.96267 -0.21238,-0.003 -0.22326,1.41955 h -2.12492 l -0.22429,-1.41955 -0.22479,0.003 -0.34829,-1.96267 h 0.26304 l -0.16692,-1.05989 h -0.1669 v -0.60099 h 0.44752 c 0.0913,-0.21026 0.18206,-0.42072 0.27336,-0.63097 z m 0.12608,0.19068 c -0.0614,0.14155 -0.12351,0.28323 -0.185,0.42478 h 2.52336 c -0.0614,-0.14155 -0.12248,-0.28323 -0.18397,-0.42478 z m -0.65524,0.63097 v 0.21911 l 0.0594,5.2e-4 h 3.35844 l 0.0724,-5.2e-4 v -0.21911 z m 0.16846,0.41083 0.1669,1.05937 h 2.80603 l 0.16693,-1.05937 -1.57046,0.008 z m -0.061,1.25057 0.27956,1.5782 1.34411,-0.0145 1.34567,0.0145 0.28059,-1.5782 z m 1.62367,1.75441 -1.08519,0.0124 0.19325,1.2299 h 1.79835 l 0.19328,-1.2299 z" id="path2714" inkscape:connector-curvature="0" />

You probably can see the code becomes more complex and needs more characters to describe it. More characters in a file result, of course, in a larger size.

Node cleaning

If you open an example SVG in Inkscape and press F2, that activates the Node tool. You should see something like this:

Inkscape - Node tool activated

Inkscape – Node tool activated

There are 5 nodes that aren’t necessary in this example — the ones in the middle of the lines. To remove them, select them one by one with the activated Node tool and press the Del key. After this, select the nodes which define this lines and make them corners again using the toolbar tool.

Inkscape - Node tool make node a corner

Inkscape – Node tool make node a corner

Without fixing the corners, handles are used that define the curve, which gets saved and will increase file size. You have to do this node cleaning by hand, as it can’t be effectively automated. Now you’re ready for the next stage.

Use the Save as function and choose Optimized svg. A dialogue window opens where you can select what to remove or keep.

Inkscape - Dialog window for save as optimized SVG

Inkscape – Dialog window for save as optimized SVG

Even the little SVG in this example got down from 3.2 KB to 920 bytes, less than a third of its original size.

Back to the getfedora page: The grey voronoi pattern used in the background of the main section, after our optimization from Part 1 of this series, is down to 164.1 KB versus the original 211.12 KB size.

The original SVG it was exported from is 1.9 MB in size. After these SVG optimization steps, it’s only 500.4KB. Too big? Well, the current blue background is 564.98 KB in size. But there’s only a small difference between the SVG and the PNG.

Compressed files

$ ls -lh insgesamt 928K -rw-r--r--. 1 user user 161K 19. Feb 19:44 grey-pattern.png -rw-rw-r--. 1 user user 160K 18. Feb 12:23 grey-pattern.png.gz -rw-r--r--. 1 user user 489K 19. Feb 19:43 greyscale-pattern-opti.svg -rw-rw-r--. 1 user user 112K 19. Feb 19:05 greyscale-pattern-opti.svg.gz

This is the output of a small test I did to visualize this topic. You should probably see that the raster graphic — the PNG — is already compressed and can’t be anymore. The opposite is the SVG, an XML file. This is just text and can compressed, to less then a fourth of its size. As a result it is now around 50 KB smaller in size than the PNG.

Modern browsers can handle compressed files natively. Therefore, a lot of web servers have switched on mod_deflate (Apache) and gzip (nginx). That’s how we save space during delivery. Check out if it’s enabled at your server here.

Tooling for production

First of all, nobody wants to always optimize SVG in Inkscape. You can run Inkscape without a GUI in batch mode, but there’s no option to convert from Inkscape SVG to optimized SVG. You can only export raster graphics this way. But there are alternatives:

  • SVGO (which seems not actively developed)
  • Scour

This example will use scour for optimization. To install it:

$ sudo dnf install scour

To automatically optimize an SVG file, run scour similarly to this:

[user@localhost ]$ scour INPUT.svg OUTPUT.svg -p 3 --create-groups --renderer-workaround --strip-xml-prolog --remove-descriptive-elements --enable-comment-stripping --disable-embed-rasters --no-line-breaks --enable-id-stripping --shorten-ids

This is the end of part two, in which you learned how to replace raster images with SVG and how to optimize it for usage. Stay tuned to the Fedora Magazine for part three, coming soon.

post

Design faster web pages, part 1: Image compression

Lots of web developers want to achieve fast loading web pages. As more page views come from mobile devices, making websites look better on smaller screens using responsive design is just one side of the coin. Browser Calories can make the difference in loading times, which satisfies not just the user but search engines that rank on loading speed. This article series covers how to slim down your web pages with tools Fedora offers.

Preparation

Before you sart to slim down your web pages, you need to identify the core issues. For this, you can use Browserdiet. It’s a browser add-on available for Firefox, Opera and Chrome and other browsers. It analyzes the performance values of the actual open web page, so you know where to start slimming down.

Next you’ll need some pages to work on. The example screenshot shows a test of getfedora.org. At first it looks very simple and responsive.

Browser Diet - values of getfedora.org

Browser Diet – values of getfedora.org

However, BrowserDiet’s page analysis shows there are 1.8MB in files downloaded. Therefore, there’s some work to do!

Web optimization

There are over 281 KB of JavaScript files, 203 KB more in CSS files, and 1.2 MB in images. Start with the biggest issue — the images. The tool set you need for this is GIMP, ImageMagick, and optipng. You can easily install them using the following command:

sudo dnf install gimp imagemagick optipng

For example, take the following file which is 6.4 KB:

First, use the file command to get some basic information about this image:

$ file cinnamon.png cinnamon.png: PNG image data, 60 x 60, 8-bit/color RGBA, non-interlaced

The image — which is only in grey and white — is saved in 8-bit/color RGBA mode. That’s not as efficient as it could be.

Start GIMP so you can set a more appropriate color mode. Open cinnamon.png in GIMP. Then go to Image>Mode and set it to greyscale. Export the image as PNG with compression factor 9. All other settings in the export dialog should be the default.

$ file cinnamon.png cinnamon.png: PNG image data, 60 x 60, 8-bit gray+alpha, non-interlaced

The output shows the file’s now in 8bit gray+alpha mode. The file size has shrunk from 6.4 KB to 2.8 KB. That’s already only 43.75% of the original size. But there’s more you can do!

You can also use the ImageMagick tool identify to provide more information about the image.

$ identify cinnamon2.png cinnamon.png PNG 60x60 60x60+0+0 8-bit Grayscale Gray 2831B 0.000u 0:00.000

This tells you the file is 2831 bytes. Jump back into GIMP, and export the file. In the export dialog disable the storing of the time stamp and the alpha channel color values to reduce this a little more. Now the file output shows:

$ identify cinnamon.png cinnamon.png PNG 60x60 60x60+0+0 8-bit Grayscale Gray 2798B 0.000u 0:00.000

Next, use optipng to losslessly optimize your PNG images. There are other tools that do similar things, including advdef (which is part of advancecomp), pngquant and pngcrush.

Run optipng on your file. Note that this will replace your original:

$ optipng -o7 cinnamon.png ** Processing: cinnamon.png 60x60 pixels, 2x8 bits/pixel, grayscale+alpha Reducing image to 8 bits/pixel, grayscale Input IDAT size = 2720 bytes Input file size = 2812 bytes Trying: zc = 9 zm = 8 zs = 0 f = 0 IDAT size = 1922 zc = 9 zm = 8 zs = 1 f = 0 IDAT size = 1920 Selecting parameters: zc = 9 zm = 8 zs = 1 f = 0 IDAT size = 1920 Output IDAT size = 1920 bytes (800 bytes decrease) Output file size = 2012 bytes (800 bytes = 28.45% decrease)

The option -o7 is the slowest to process, but provides the best end results. You’ve knocked 800 more bytes off the file size, which is now 2012 bytes.

To resize all of the PNGs in a directory, use this command:

$ optipng -o7 -dir=<directory> *.png

The option -dir lets you give a target directory for the output. If this option is not used, optipng would overwrite the original images.

Choosing the right file format

When it comes to pictures for the usage in the internet, you have the choice between:

JPG-LS and JPG 2000 are not widely used. Only a few digital cameras support these formats, so they can be ignored. aPNG is an animated PNG, and not widely used either.

You could save a few bytes more through changing the compression rate or choosing another file format. The first option you can’t do in GIMP, as it’s already using the highest compression rate. As there are no alpha channels in the picture, you can choose JPG as file format instead. For now use the default value of 90% quality — you could change it down to 85%, but then alias effects become visible. This saves a few bytes more:

$ identify cinnamon.jpg cinnamon.jpg JPEG 60x60 60x60+0+0 8-bit sRGB 2676B 0.000u 0:00.000

Alone this conversion to the right color space and choosing JPG as file format brought down the file size from 23 KB to 12.3 KB, a reduction of nearly 50%.

PNG vs. JPG: quality and compression rate

So what about the rest of the images? This method would work for all the other pictures, except the Fedora “flavor” logos and the logos for the four foundations. Those are presented on a white background.

One of the main differences between PNG and JPG is that JPG has no alpha channel. Therefore it can’t handle transparency. If you rework these images by using a JPG on a white background, you can reduce the file size from 40.7 KB to 28.3 KB.

Now there are four more images you can rework: the backgrounds. For the grey background, set the mode to greyscale again. With this bigger picture, the savings also is bigger. It shrinks from 216.2 KB to 51.0 KB — it’s now barely 25% of its original size. All in all, you’ve shrunk 481.1 KB down to 191.5 KB — only 39.8% of the starting size.

Quality vs. Quantity

Another difference between PNG and JPG is the quality. PNG is a lossless compressed raster graphics format. But JPG loses size through compression, and thus affects quality. That doesn’t mean you shouldn’t use JPG, though. But you have to find a balance between file size and quality.

Achievement

This is the end of Part 1. After following the techniques described above, here are the results:

You brought image size down to 488.9 KB versus 1.2MB at the start. That’s only about a third of the size, just through optimizing with optipng. This page can probably be made to load faster still. On the scale from snail to hypersonic, it’s not reached racing car speed yet!

Finally you can check the results in Google Insights, for example:

In the Mobile area the page gathered 10 points on scoring, but is still in the Medium sector. It looks totally different for the Desktop, which has gone from 62/100 to 91/100 and went up to Good. As mentioned before, this test isn’t the be all and end all. Consider scores such as these to help you go in the right direction. Keep in mind you’re optimizing for the user experience, and not for a search engine.

post

Play Windows games on Fedora with Steam Play and Proton

Some weeks ago, Steam announced a new addition to Steam Play with Linux support for Windows games using Proton, a fork from WINE. This capability is still in beta, and not all games work. Here are some more details about Steam and Proton.

According to the Steam website, there are new features in the beta release:

  • Windows games with no Linux version currently available can now be installed and run directly from the Linux Steam client, complete with native Steamworks and OpenVR support.
  • DirectX 11 and 12 implementations are now based on Vulkan, which improves game compatibility and reduces performance impact.
  • Fullscreen support has been improved. Fullscreen games seamlessly stretch to the desired display without interfering with the native monitor resolution or requiring the use of a virtual desktop.
  • Improved game controller support. Games automatically recognize all controllers supported by Steam. Expect more out-of-the-box controller compatibility than even the original version of the game.
  • Performance for multi-threaded games has been greatly improved compared to vanilla WINE.

Installation

If you’re interested in trying Steam with Proton out, just follow these easy steps. (Note that you can ignore the first steps to enable the Steam Beta if you have the latest updated version of Steam installed. In that case you no longer need Steam Beta to use Proton.)

Open up Steam and log in to your account. This example screenshot shows support for only 22 games before enabling Proton.

Now click on Steam option on top of the client. This displays a drop down menu. Then select Settings.

Now the settings window pops up. Select the Account option and next to Beta participation, click on change.

Now change None to Steam Beta Update.

Click on OK and a prompt asks you to restart.

Let Steam download the update. This can take a while depending on your internet speed and computer resources.

After restarting, go back to the Settings window. This time you’ll see a new option. Make sure the check boxes for Enable Steam Play for supported titles, Enable Steam Play for all titles and Use this tool instead of game-specific selections from Steam are enabled. The compatibility tool should be Proton.

The Steam client asks you to restart. Do so, and once you log back into your Steam account, your game library for Linux should be extended.

Installing a Windows game using Steam Play

Now that you have Proton enabled, install a game. Select the title you want and you’ll find the process is similar to installing a normal game on Steam, as shown in these screenshots.

After the game is done downloading and installing, you can play it.

Some games may be affected by the beta nature of Proton. The game in this example, Chantelise, had no audio and a low frame rate. Keep in mind this capability is still in beta and Fedora is not responsible for results. If you’d like to read further, the community has created a Google doc with a list of games that have been tested.
